• Model NO.：235-60
• HS Code：8466100000
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. 235-60 HS Code 8466100000 Production Capacity 1000PCS/Month

Product Description

Model A
Vertical of centre line of spindle to base surface: 0.0008"
Base: 4x7-7/8"
Height: 4-1/2"
Model No. 235-6090

Model B
Parallelism of centre line of spindle to base surface(horizontal): 0.0008"
Vertical of centre line of spindle to base surface (Vertical): 0.0008"
Center Height: 2.52"
Base: 4-1/4x5"
Height: 4-1/2"
Model No. 235-6095

Model C
Parallelism of centre line of spindle to base surface(horizontal): 0.0008"
Vertical of centre line of spindle to base surface (Vertical): 0.0008"
Base in Horizontal: 5x3.96"
Height in Horizontal: 3.74"
Base in Vertical: 5x3.74"
Height in Vertical: 4.13"
Model No. 235-6080

Model D
Parallelism of centre line of spindle to base surface(horizontal): 0.0008"
Vertical of centre line of spindle to base surface (Vertical): 0.0008"
Base in Horizontal: 6.1x4.03"
Height in Horizontal: 7.16"
Base in Vertical: 6.1x4.72"
Height in Vertical: 4.13"
Model No. 235-6085
