0.8-4.2mm Wire Forming Machine Auto Spring Making Machine
Dongguan Hua Yi Da Spring Machinery Co., Ltd.- Function：Pressed, Phonation, Buffer, Drive, Restoration, Measurement, Forming
- Material：Stainless Steel
- Usage：Industrial, Auto, Furniture, Motorcycle, Home Appliance, Seat
- Load Type：Bend
- Production Process：Cold Roll
- Shape：Cylinder
Base Info
- Model NO.：HYD-40T-3A
- Axis Count：3
- Wire Size Range：0.8-4.2mm
- Max Feeding Speed：110m,Min
- Cam Setting Value：±0.1°~±359.9°
- Max Outside Dia：60mm
- Max Production：60PCS,Min
- Weight：1800kg
- Wire Feeding Servo Motor：5.5kw
- Cam Servo Motor：5.5kw
- Machine Size：1600X1300X1900mm
- Transport Package：Standard Wooden Box
- Specification：BV
- Trademark：HYD
- Origin：Dongguan
- HS Code：8463300000
- Production Capacity：300PCS,Year
Description
Three-axis multi-functional spring machineModel HYD-40T-3A Diameter 0.8~4.2mm Max OD 60mm Feeding speed 0~110m/min Cam command value ±0.1°~±359.9° Transmission speed cam 0~60RPM Wire feed servo motor 5.5KW Can servo motor 5.5KW Rotary servo motors 1.0KW Power 380V±10%V50Hz Machine size 1600*1300*1900mm Weight 1800kg
HYD Services:
1. Free training is provided in HYD production base.Pictures and video of the machine operation will be sent for confirmation before shipment.
2 .The professional and patient consulting service will help you find the suitable solution.
3. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.
4 HYD provide technical support by email and phone,technicians will be available at your side if necessary.
5 Spare parts will be freely supplied during the guarantee period(one year), original cost after this period.
FAQ
1. Q: What information will be helping to get an accurate quotation from us?
A: The customer should provide the related drawings, pictures, industrial voltage, planned output, technical requirements, etc
2. Q: What is the power supply of the machine?
A: The standard power supply in China is 380V, 3P, 50Hz. We also can customized as per requirement.
3. Q: What is the payment term
A: The payment term is 30% deposit as PO confirmation ,and 70% should be finished before the shipment.We also accept other payment term.
4 Q: What is the delivery time?
A: Normally the delivery time of the machine is 30 days after receiving deposit.But it depends on machine model.Some of them could be shipped within 10 days.
5. Q: What is the guarantee period of the machine?
A: The guarantee period is one year from the date of B/L.
HYD Services:
1. Free training is provided in HYD production base.Pictures and video of the machine operation will be sent for confirmation before shipment.
2 .The professional and patient consulting service will help you find the suitable solution.
3. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.
4 HYD provide technical support by email and phone,technicians will be available at your side if necessary.
5 Spare parts will be freely supplied during the guarantee period(one year), original cost after this period.
FAQ
1. Q: What information will be helping to get an accurate quotation from us?
A: The customer should provide the related drawings, pictures, industrial voltage, planned output, technical requirements, etc
2. Q: What is the power supply of the machine?
A: The standard power supply in China is 380V, 3P, 50Hz. We also can customized as per requirement.
3. Q: What is the payment term
A: The payment term is 30% deposit as PO confirmation ,and 70% should be finished before the shipment.We also accept other payment term.
4 Q: What is the delivery time?
A: Normally the delivery time of the machine is 30 days after receiving deposit.But it depends on machine model.Some of them could be shipped within 10 days.
5. Q: What is the guarantee period of the machine?
A: The guarantee period is one year from the date of B/L.
