• Model NO.：PM,31082
• N.W.：3.1 Kg
• Warranty：One Year
• Pressure Ability：0.2-0.8 M PA
• Air Inlet：G1,2
• Color：Black
• Top Plate Diameter (Width)：135 mm
• Bottom Plate Diameter (Width)：135 mm
• Stroke Rubber Bellows：75~230 mm
• Bumper Block：Without
• Screw (Nut)：M8
• Transport Package：Cartons
• Specification：24*24*24 cm
• Trademark：Norgren
• Origin：Europe
• HS Code：8708809000
• Production Capacity：5000PCS,Month

Type

Order No.

Rubber bellows only

66501

with dismountable plates, G1/2 air inlet

66505

Min. pressure 0 bar
Return force to min height ≤ 300 N
Overall weight 3.5 kg

Vibration isolation - dynamic characteristic values

Design height H: recommended 200mm, minimum 180mm

Pressure p [bar]

3

4

5

6

7

8

Vol. V [l]

Force (Load) [kN]

3.9

5.3

6.7

8.2

9.7

11.3

Spring rate [N/mm]

76

97

118.5

140

161

181.5

4.1

Natural frequency [Hz]

2.2

2.2

2.1

2.1

2.1

2.0

Pneumatic application - static characteristic values

Force F [kN]

Pressure p [bar]

3

4

5

6

7

8

Vol. V [l]

Height H [mm]

220

2.9

4.03

5.16

6.41

7.65

8.98

4.3

200

3.86

5.27

6.68

8.21

9.73

11.3

4.1

150

5.9

8

10.1

12.4

14.7

16.9

3.2

100

8.2

10.9

13.7

16.6

19.4

22.4

2
