• Model NO.：JIS Type
• Part No.：Rjas0050-Rjas0280
• Size：5mm-28mm
• Wll：90kgs-2500kgs
• I.L.：19mm-115mm
• N.W.：0.026kgs-2.65kgs
• Transport Package：Packing in Cartons or Bags Then Into Pallet
• Specification：ISO
• Trademark：H-Quality,OEM
• Origin：China Mainland
• HS Code：73269090
• Production Capacity：1000t Per Month

Basic Info.

Model NO. JIS Type Part No. Rjas0050-Rjas0280 Size 5mm-28mm Wll 90kgs-2500kgs I.L. 19mm-115mm N.W. 0.026kgs-2.65kgs Transport Package Packing in Cartons or Bags Then Into Pallet Specification ISO Trademark H-Quality/OEM Origin China Mainland HS Code 73269090 Production Capacity 1000t Per Month

Product Description

We can supply many kinds of shackles, such as:

1) Drop forged US type load rated shackle 209, 210, 2130, 2150, 213, 215
2) Commercial grade US type shackle, screw pin anchor shackle, chain shackle
3) European type large bow and dee shackle
4) Trawling chain shackle with square head
5) Large bow and large dee BS3032 shackle

If you have any need, Pls do not hesitate to let us know. You can have a look to our website.

Inner packing:
Carton

Part No	Size mm	W. L. L. kgs	I. L. mm	N. W. kg
RJAS0050	5	90	19	0.026
RJAS0060	6	150	25	0.028
RJAS0080	8	250	32	0.065
RJAS0100	10	400	38	0.080
RJAS0120	12	600	51	0.200
RJAS0160	16	800	64	0.495
RJAS0200	20	1000	76	0.800
RJAS0220	22	1500	89	1.260
RJAS0250	25	2000	100	1.900
RJAS0280	28	2500	115	2.650

Brand name	H-quality
Usage	Lifting and connecting, Wire rope fittings, Chain fittings, Marine hardware fittings
Packing	carton and pallet / by customer requirements.
Delivery time	3-20days after order confirmation
Payment term	T/T, L/C
Business type	Manufacturer, trading
Certifications	ISO9001,CE,BV,SGS
Notes	Special specifications and marks can be made according to customers requirements;
Main products	Aluminum Sleeves, Copper Sleeves, Steel Sleeves, Eye bolts, Shackles, Turnbuckles, Wire Rope Clips, Load binders, Lifting Hooks, Connecting Links, Master Links, Swivels and many other rigging hardware.

FAQ
1.What's your advantage compared to your competitor?
We are very strict in the products quality. We have superior service, competitive price and on-time delivery.
2.How to place an order?
Please send us your purchase order by email to or call us .
3.How long can I get the sample?
If we have the product in stock, we can send it to you once we get your contact information. The samples can be sent to you via DHL,UPS,TNT,FEDEX or other international express.
4.How can order the products without any acknowledge of import?
We can send products to you by international express or our shipping agent can arrange shipment by sea/air for you.
