3 Bolt Aluminium Alloy Parallel Groove Clamp APG-B3 for Pole Line Cable Fitting
Victory Electric Power Equipment Co., Ltd.- Material：Aluminium
- Structure：G Clamp
- Standard：Standard
- Condition：New
- Brand：Vic
- Name：Parallel Clamp
Base Info
- Model NO.：APG-B3
- Gender：Male
- Certification：ISO9001 IEC
- Finish：Hot DIP Galvanized
- Transport Package：Caton or as Your Required
- Specification：ANSI
- Trademark：VIC
- Origin：Zhejiang Wenzhou
- HS Code：8535900090
- Production Capacity：800000PCS,Month
Description
Type
Product Description
Material:Body:High strength,corrosion-resistant,aluminium 99.5
Bolts:DIN933,steel8.8.Dacroment.Nut:DIN93.4,Dacromet.pressed into lower part.
Pressure Pad:aluminium alloy Spring washers:DIN127,steel
Concial Washer(according to order):DIN6796,corrosion-protected
Stainless steel A 2bolts and nuts avaiabale according to order:
Recommended Torque momnets:M8:23NmM10:46Nm
CAPG is used for tapping or jointing copper conductor to aluminum overhead conductors AAC, AAAC, or ACSR. Forging creates a high strength clamp. slotted holes allow adjustment for varying conductors to each side. Tap off conductor groove is lined with hot compressed copper sheet on both upper and lower parts. Contact area between copper and aluminum is sealed with epoxy resin. threaded bottom part of connector can provide easy installation. its tpe test is in accordance with IEC .
Packaging & Shipping
Usually we pack goods by box, wooden cases or according to client's requirements to adjust. We will be responsible for packing the stores suitable for transit by sea/ rail/ road so as to ensure their being free from loss. Usually we export the product on Tianjin Port . We will do our best to meet the client's requirements.
Zhejiang Victory Electric Power Fitting Co.,Ltd. has been engaged in designing and making in producing electric power fittings and poleline accessories more than 20 years, and has got the certificate of International Quality System ISO9001.
Our company has products of all specifications and its major products are overhead insulator fittings, poleline accessories, power line fittings, pocelain insulators and so on. The company has a strong technological power, top-ranking production.
