• Model NO.：414
• HS Code：73269090
• Production Capacity：1000t Per Month

Basic Info.

Model NO. 414 HS Code 73269090 Production Capacity 1000t Per Month

Product Description

AS a professional manufacturer, our products are various, such as 411, 414, DIN6899A, DIN6899B, BS464 etc.

Material: Stainless steel (SS316, SS304), 20# (carbon steel), alloy steel.
Surface treatment: Electro galvanized, hot dipping galvanized or according to customers' requirements.
Standard: Meets to the performance requirements of Federal Specification FF-T-276b Type II, except for those provisions required of the contractor.
Price term: FOB Qingdao/China port.

Part No.	Rope Dia. (inch)	Weigthper 100(ibs)					Dimensions(inch)
			A	B	C	D	E	F	G	H
RHDT0104	1/4"	6.50	2.19	1.62	1.50	0.88	0.41	0.28	0.06	0.25
RHDT0516	5/16"	11.80	2.50	1.88	1.81	1.06	0.50	0.34	0.08	0.30
RHDT0308	3/8"	21.60	2.88	2.12	2.12	1.12	0.63	0.41	0.11	0.39
RHDT0716	7/16"	34.70	3.25	2.38	2.38	1.25	0.72	0.47	0.12	0.45
RHDT0916	1/2-9/16"	51.00	3.62	2.75	2.75	1.50	0.89	0.59	0.15	0.48
RHDT0508	5/8"	75.70	4.25	3.25	3.12	1.75	1.00	0.66	0.16	0.53
RHDT0304	3/4"	158.10	5.00	3.75	3.81	2.00	1.22	0.78	0.22	0.69
RHDT0708	7/8"	177.80	5.50	4.25	4.25	2.25	1.38	0.94	0.22	0.78
RHDT1000	1"	313.90	6.12	4.50	4.75	2.50	1.56	1.06	0.25	0.88
RHDT1104	1-1/8-1-1/4"	400.00	7.00	5.12	5.88	2.88	1.88	1.31	0.25	1.25
RHDT1308	1-1/4-1-3/8"	886.00	9.08	6.50	6.81	3.50	2.25	1.44	0.37	1.29
RHDT1102	1-3/8-1-1/2"	1294.00	9.00	6.25	7.12	3.50	2.62	1.56	0.50	1.31
RHDT1508	1-5/8"	1700.00	11.25	8.00	8.12	4.00	3.00	1.72	0.50	1.38
RHDT1304	1-3/4"	1775.00	12.19	9.00	8.50	4.50	3.06	1.84	0.50	1.50
RHDT2000	1-7/8-2" :	2775.00	15.12	12.00	10.38	6.00	3.38	2.09	0.50	1.69
RHDT2104	2-1/4" :	3950.00	17.50	14.00	11.88	7.00	3.88	2.38	0.62	1.82

Brand name	H-quality
Usage	Lifting and connecting, Wire rope fittings, Chain fittings, Marine hardware fittings
Packing	carton and pallet / by customer requirements.
Delivery time	3-20days after order confirmation
Payment term	T/T, L/C
Business type	Manufacturer, trading
Certifications	ISO9001,CE,BV,SGS
Notes	Special specifications and marks can be made according to customers requirements;
Main products	Aluminum Sleeves, Copper Sleeves, Steel Sleeves, Eye bolts, Shackles, Turnbuckles, Wire Rope Clips, Load binders, Lifting Hooks, Connecting Links, Master Links, Swivels and many other rigging hardware.

FAQ:
1.What's your advantage compared to your competitor?
   We are very strict in the products quality. We have superior service, competitive price and on-time delivery.
2.How to place an order?
   Please send us your purchase order by email or call us sales line:
3.How long can I get the sample?
   If we have the product in stock, we can send it to you once we get your contact information. The samples can be sent to you via DHL, UPS, TNT, FEDEX or other international express.
4.How can order the products without any acknowledge of import?
   We can send products to you by international express or our shipping agent can arrange shipment by sea/air for you.
