Grade 100 Short Link Lifting Chain
Qingdao Powerful Machinery Co., Ltd.- Usage：Transmission Chain, Drag Chain, Dedicated Special Chain
- Material：Alloy
- Surface Treatment：Oxygenation
- Feature：Oil Resistant
- Chain Size：8-22mm
- Structure：Welded Chain
Base Info
- Model NO.：G100
- Color：Silver
- Inside Length：24-66mm
- Inside Width：24.7-68mm
- Deviation Min：23.3-64
- Weight：1.4-10.9kg,M
- Working Load：25-190kn
- Proof Load：62-475kn
- Breaking Load：100-760kn
- Transport Package：Iron Drum
- Specification：8-22mm
- Trademark：NM
- Origin：China
- HS Code：73158200
- Production Capacity：500000m,Y
Description
G100 SHORT LINK LIFTING CHAINSize
mm Pitch
mm Deviation
Max Deviation
Min Inside Width
mm Outside Width
mm Weight
Kg/m Working Load
Kn Proof Load
Kn Break Load
Kn 8 24.00 24.70 23.30 10.40 29.60 1.40 25 62 100 10 30.00 30.90 29.10 13.00 37.00 2.20 39 98 157 13 39.00 40.20 37.80 16.90 48.10 3.80 66 165 265 16 48.00 49.40 46.60 20.80 59.20 5.70 100 251 402 18 54.00 55.60 52.40 23.40 66.60 7.30 127 317 508 20 60.00 61.80 58.20 26.00 74.00 9.00 157 392 628 22 66.00 68.00 64.00 28.60 81.40 10.90 190 475 760
Packing details:
Company Introduction:
Qingdao Powerful Machinery Co., Ltd. is located in Qingdao, one of the largest
port city in China,. As China leading manufacturer for rigging, lifting, and material
handling applications, Powerful Machinery delivers a diverse portfolio of products
engineered to exceed the toughest demands of any industry, construction, cargo
handling, towing, marine, and transportation.
Our products include welded chain, G80 and G100 lifting chain & accessories,
hooks, shackles, hoist rings, master links, chain slings, turnbuckles, snatch blocks,
wire rope & fittings, webbing products, lifting products, marine products, stainless
steel products and a host of other custom engineered solutions: the most comprehensive
portfolio in the industry.
Powerful Machinery has 20 years of export experience, with customers in dozens of
countries around the world. Our products are exported to Europe, America, Southeast
Asia, the Middle East, Australia and many other regions.
At Powerful Machinery, We have a team of professionals working together to provide
our customers with the best products and services. When you choose Powerful Machinery,
you are guaranteed more than superior products-you are guaranteed the quality assurance
that comes with a customer service team committed to exceeding end user expectations.
At Powerful Machinery, it's not just about lifting products; it's about working with a trusted
partner who is invested in your success.
