Nll-1 Mv Bolted Type Alluminum Alloy Strain Clamp Tension Clamp
L&R ELECTRIC GROUP CO., LTD.- Type：Nll-1
- Conductor Size：5.0-10.0mm
Base Info
- Model NO.：NLL-1
- U Bolt Size：M10*2PCS
- Ultimate Tensile Strength：40kn
- Material：Alluminum Alloy
- Transport Package：Wooden Pallet
- Specification：NLL,NLD
- Trademark：L&R
- Origin：China
- HS Code：853890000
- Production Capacity：5000PCS,Week
- Package size per unit product：10.00cm * 10.00cm * 15.00cm
- Gross weight per unit product：1.500kg
Description
TypeDiameter of
stranded wire U bolt U.T.S(KN) Cover used Nos Dia NLL-1 5.0-10.0 2 M10 40 JNL-1 NLL-2 10.1-14.0 2 M12 40 JNL-2 NLL-3 14.1-18.0 3 M12 70 JNL-3 NLL-4 18.1-23.0 3 M12 90 JNL-4 NLL-5 23.1-29.0 5 M12 120 JNL-5 NLL-35/6 8.16 2 M10 12 NLL-70/12 11.4 3 M10 28 NLL-120/20 15.07 3 M10 40
Diameter of Conductor(mm)Dimensions(mm) Bolt Ultimate Strength(kn) D C L I No. Dia(mm) NLD-1 5.0-10.0 16 18 150 120 2 12 18 NLD-2 10.1-14.0 16 18 205 130 3 12 41 NLD-3 14.1-18.0 18 22 310 160 4 16 71 NLD-4 18.1-23.0 18 25 410 220 5 16 91
stranded wire
Diameter of Conductor(mm)
