AISI 304316 Link Chain of DIN764 with Durable Modeling
Qingdao Haito Rigging Hardware Co., Ltd.- Usage：Transmission Chain
- Material：Stainless steel
- Surface Treatment：Polishing
- Feature：Heat Resistant
- Chain Size：2-28mm
- Structure：Welded Chain
Base Info
- Model NO.：din764
- Color：Silver
- Size：as Requested
- Surface Finish：High Polished
- Advantage：Fast Delivery
- Certification：SGS
- Type：High Quality
- Design：OEM Services Provided
- Brand：Haito
- Transport Package：Drum and Pallet
- Specification：2-28MM
- Trademark：Haito
- Origin：Qingdao, China
- HS Code：7315820000
- Production Capacity：50ton,Month
Description
DIN 763 LINK CHAINSIZE INSIDE LENGHT OUTSIDE WIDTH WORKING LOAD TEST LOAD BREAKING LOAD WEIGHT
PER M MM ±MM MM ±MM MM ±MM KG N N KG 2 0.5 22 1.0 8 0.4 25 800 1250 0.06 2.5 24 1.1 10 0.5 40 800 2000 0.1 3 26 1.2 12 0.6 55 1050 3200 0.15 3.5 28 1.3 14 0.7 80 1540 3850 0.20 4 32 1.5 16 0.8 100 2000 6000 0.27 4.5 34 1.7 18 0.9 128 2500 6300 0.35 5 35 1.8 20 1.0 160 3150 10000 0.43 5.5 38.5 1.8 22 1.1 195 3800 9500 0.52 6 42 2.0 24 1.2 224 4500 14000 0.63 7 49 2.5 28 1.4 300 6000 18000 0.86 8 52 2.5 32 1.6 400 8000 25000 1.10 8.5 56 2.8 34 1.7 460 9000 22500 1.25 9 59 3.0 36 1.8 530 10500 32000 1.41 10 1 65 3.2 40 2.0 630 12500 40000 1.75 11 72 3.4 44 2.0 790 15800 47500 2.11 12 78 3.6 48 2.3 940 18800 56500 2.55 13 82 4.0 52 2.5 1000 21200 63000 2.95 16 100 5.0 64 3.2 1600 33000 100000 4.45 18 113 5.2 70 3.2 2120 42300 127000 5.65 19 119 5.6 72 3.4 2370 47300 142000 6.25 20 120 6.0 75 3.8 2500 50000 160000 7.00 22 127 6.0 82 4.0 3170 63300 190000 8.55 25 140 6.6 85 4.2 4090 81700 245000 10.9 28 152 7 96 4.7 6000 120000 300000 13.9 171 7.8 108 5.2 8000 160000 400000 18.2
About us
Haito stainless Co., Ltd. was founded in 1998.Specializing in the production of stainless
shackle,turnbuckle,terminal,screw and other metal products.Products of high quality,
fashionable, windely used in a variety of architecture, not only has the broad masses of the
domestic sales market,but also exported to Europe and the United States. Over the past few
years of production and management and exploration,Founder set up its own quality
management system. Passed the ISO9001:2008 quality system certification Founder always
implement the concept of customer value creation for customers tailored products to meet
the needs of different customers, and continuously provide customers with solutions
and technical problems. Further exploration and innovation, and excellence. Warmly
welcome you and opening up the boundaries of communication. We synchronize with your
ideal partner! we can produce many kinds of body for shackles, we export shackles to
all over the world. we can produce all sizes of shackles and can produce special shackles in
accordance with the customers' requirements.
