50mm Swivel Screw with Brake PP Wheel Caster
Hubei Space Double Rhombus Logistics Technology Co., Ltd.- Style Name：Plastic Caster
- Application：Instrumental Equipment
- Material：Plastic
- Wheel Diameter：50,75,100,125mm
- Wheel Width：20,25,30,30mm
- Housing Material：Zinc Plated Steel Housing
Base Info
- Model NO.：L110-30B050X20IS
- Load Capacity：40kg-90kg
- Over Height：75.5mm-163.5mm
- Offset：26mm-39mm
- Transport Package：Export Carton for Instrumental Caster
- Specification：GB; ISO, BSCI, SGS, REACH, ROHS
- Trademark：DOUBLE RHOMUBS
- Origin：Hubei, China
- HS Code：87169000
- Production Capacity：5000000PCS,Month for Caster
Description
Basic Info.
Model NO. L110-30B050X20IS Load Capacity 40kg-90kg Over Height 75.5mm-163.5mm Offset 26mm-39mm Transport Package Export Carton for Instrumental Caster Specification GB; ISO, BSCI, SGS, REACH, ROHS Trademark DOUBLE RHOMUBS Origin Hubei, China HS Code 87169000 Production Capacity 5000000PCS/Month for CasterProduct Description
Parameter| Model No. | L110-30B050x20IS | Diameter of stem | 3/8" |
| Wheel material | Polypropylene | Length of stem | 15mm |
| Wheel diameter | 50mm | Load capacity | 40kg |
| Wheel width | 20mm | Brake | Yes |
| Overall height | 75.5mm | Bracket thickness | 1.5mm |
| Offset | 26mm | Housing material | Stamped and galvanized steel |
| Application | Instrnments, equipments |
Instrumental Caster's general features:
1. This kind of casters are for instrumental equipments.
2. Steel housing with zinc plating and plastic braked pedal.
3. There are two kinds of wheels to choose:
A). 30C: Polypropylene wheel, plain bearing
B). 20C: Nylon wheel, plain bearing,
4. Caster code: (as follows: 30B "B" means unitary bearing; 30C, "C" means plain bearing. )
5. There are four Wheel size for you to choose:
A). 50*20mm,
B). 75*25mm,
C). 100*30mm,
D). 125*30mm.
6. Different types for you to select:
A). Fixed plate type caster,
B). Swivel plate caster with or without brake,
C). Screw stem caster with or without brake
D). Bolt hole caster with or without brake.
Payment and delivery:
1. Payment: By T/T.
2. Delivery time: Producing time will be from 2 weeks to 4 weeks generally.
***If there are any caster you are interested in, please send us an inquiry, if you couldn't find what you want, please also let us know, we could make new caster specially.
| Model No. | L110-30B050x20IS | Diameter of stem | 3/8" |
| Wheel material | Polypropylene | Length of stem | 15mm |
| Wheel diameter | 50mm | Load capacity | 40kg |
| Wheel width | 20mm | Brake | Yes |
| Overall height | 75.5mm | Bracket thickness | 1.5mm |
| Offset | 26mm | Housing material | Stamped and galvanized steel |
| Application | Instrnments, equipments |
