Lifting Equipment Wire Rope Pulling Hosit
Qingdao Yanfei Rigging Co., Ltd.- Usage:Lifting
- Material:Aluminum
- Surface Treatment:Polishing
- Feature:Wire Rope Pulling Hoist
- Chain Size:Wire Rope Pulling Hoist
- Structure:Wire Rope Pulling Hoist
Base Info
- Model NO.:wire rope pulling hoist
- Product Name:Wire Rope Pulling Hoist
- Capacity:0.8t-5.4t
- Other:Wire Rope Winch, Cable Pulling Equipment
- Packing:Carton Packing, Then Wooden Pallet
- Place of Origin:Shandong, China
- Transport Package:Carton Packing, Then Wooden Pallet
- Specification:CE
- Trademark:YANFEI,OEM
- Origin:China
- HS Code:842519000
- Production Capacity:10000PCS,Month
Description
Specifications of Wire Rope HoistModel W008 W016 W032 W054 Rated Capacity kg 800 1600 3200 5400 Rope Advance per Full Stroke mm ≥52 ≥55 ≥28 ≥25 Lever Pull at WLL N 341 400 438 850 Rope Diameter mm 8.3 11 16 20 Standard Length of Wire Rope m 20 20 20 20 Net Weight Without Cable kg 6.4 12 23 58 Cable Weight kg 8.5 16.5 25 36 Max.Overall Size(mm) A 430 548 660 930 B 238 284 335 390 C 64 97 116 150 L1(cm) 70 70 70 L2(cm) 80 120 120 120
