• Model NO.：80 Grade Chain
• Color：Solid Color
• Place of Origin：Shanghai, China (Mainland)
• Brand Name：Hugo
• Model Number：80 Grade Chain
• Function：Drag Chain
• Standard or Nonstandard：Standard
• Diameter：10mm
• Unit Weight：2.2,M
• Breaking Load：125kn
• Test Load：Test Load
• Transport Package：Carton, Plywood, Pallet
• Specification：CE ISO
• Trademark：HUGO
• Origin：Shanghai, China
• HS Code：7315
• Production Capacity：10000,Month

Basic Info.

Model NO. 80 Grade Chain Color Solid Color Place of Origin Shanghai, China (Mainland) Brand Name Hugo Model Number 80 Grade Chain Function Drag Chain Standard or Nonstandard Standard Diameter 10mm Unit Weight 2.2/M Breaking Load 125kn Test Load Test Load Transport Package Carton, Plywood, Pallet Specification CE ISO Trademark HUGO Origin Shanghai, China HS Code 7315 Production Capacity 10000/Month

Product Description

1. Introduction of High Quality Link Chain Alloy Stainless Steel Chain G80
1)Surface treatment: Electro galvanized link chain, hot dipping galvanized link chain, zinc plated (white, blue, yellow, color zinc plating), blackened link chain, self color link chain, black oxide link chain)
2)Standard: Ordinary mild steel link chain, short link chain, medium link chain, long link chain,
American Standard link chain (ASTM1980, NACM1990, NACM1996/NACM2003)
Germany Standard link chain(DIN5685A/C short/long link chain, DIN763/DIN764, DIN766)
Australian Standard,
Japan Standard,
Korea Standard,
Norwegian Standard link chain;
3)Grade: G30, G43, G70, G80
4)Diameter/Size: 1/8inch to 1 inch, it is 3mm to 28mm
5)Material: SS316, SS304(Stainless steel, 20Mn2, Q235(carbon steel), alloy steel
6)Usage: Lashing, transportation, transmission, construction, fence, shop decoration, swing, fishing, lifting chain, hardware chain, anchor chain, snow chain, animal chain, elevator balance chain etc.
7)packing: Gunny bag, plastic reel with carton, plastic bucket, steel bucket/drum/pails, plywood case, plywood pallet, iron pallet as customers'choice.
4). Competitive price

5). High efficiency, high durability and labor saving

6). Reliable in quality and service

(7) Warranty: 1 year

2. Parameters of High Quality Link Chain Alloy Stainless Steel Chain G80


Material Diameter inch	Inside Length mm	Inside Width mm	Max Wording Load kn	Test Load kn	Min Breaking Load kn	Weight kg/m
6±0.2	18±0.5	8	9.8	25	40	0.79
7±0.3	21±0.6	10.3	14.7	40	60	1.10
8±0.3	24±0.7	10.8	19.6	50	80	1.45
10±0.4	30±0.9	13.5	31.4	80	125	2.20
13±0.5	39±1.2	17.5	49.0	125	200	3.70
