U-Bolt with Nut From Chinese Manufacturer
Weifang First Rigging Co., Ltd.- Product Name：U-Bolt with Nut
- Application：Machinery, Chemical Industry, Environmental, Build
- Transport Package：General Export Package
- Specification：YZR1501-6x50---8x95
- Trademark：First Rigging
- Origin：Shandong China
Base Info
- Model NO.：FST-ULS-01
- HS Code：7616100000
- Production Capacity：150ton,Month
Description
Basic Info.
Model NO. FST-ULS-01 HS Code 7616100000 Production Capacity 150ton/MonthProduct Description
U-Bolt with Nut from Chinese ManufactureSize:YZR1501-6x50---8x95
Material: Stainless Steel, Carbon Steel,Hot-Rolled Steel
Surface treatment: Galvanized, Polishing
Application: Machinery, Chemical Industry, Environmental, Building
Technical Specification:
| SIZE | A | B | C | D | E | F | G | H | L | N.W |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | g/pcs |
| 6 | 50 | 2 | 25 | 5.2 | 16 | 5.5 | 5 | 16 | 66 | 32 |
| 6 | 55 | 2 | 29 | 5.2 | 16 | 5.5 | 5 | 16 | 70 | 35 |
| 8 | 95 | 2 | 29 | 6.9 | 16 | 9 | 5 | 16 | 70 | 65 |
| 8 | 82 | 2 | 43 | 6.9 | 16 | 9 | 5 | 16 | 85 | 79 |
| 8 | 113 | 2 | 43 | 6.9 | 16 | 9 | 5 | 16 | 85 | 94 |
| 8 | 82 | 2 | 50 | 6.9 | 16 | 9 | 5 | 16 | 92 | 98 |
| 8 | 130 | 2 | 50 | 6.9 | 16 | 9 | 5 | 16 | 92 | 110 |
| 8 | 70 | 2 | 35 | 6.9 | 16 | 9 | 5 | 16 | 77 | 69 |
| 8 | 104 | 2 | 35 | 6.9 | 16 | 9 | 5 | 16 | 77 | 85 |
| 8 | 140 | 2 | 68 | 6.9 | 16 | 9 | 5 | 16 | 110 | 125 |
| 8 | 95 | 2 | 60 | 6.9 | 16 | 9 | 5 | 16 | 102 | 95 |
Packaging & Delivery:
Packing details:
Bulk packing
Packed in wooden cases
Packed in Iron drum, then in pallets
According to your requirements
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
