• Model NO.：Weldless Ring,Master Links,Master Link Assembly
• Transport Package：as Customer Requirement
• Specification：CE, ISO9001
• Trademark：Thinkwell
• Origin：China
• HS Code：73269090
• Production Capacity：20000PCS Per Day

Basic Info.

Model NO. Weldless Ring/Master Links/Master Link Assembly Transport Package as Customer Requirement Specification CE, ISO9001 Trademark Thinkwell Origin China HS Code 73269090 Production Capacity 20000PCS Per Day

Product Description

High Quality Painted Color Weldless Ring Master Link


These round rings are made from weldless, forged steel. They are commonly used in many rigging scenarios, such as with ring chokers for logging. Because they are load-rated and carry a safety factor of 5:1, we can install them on slings and bridles as needed provided the Working Load Limit (clearly marked on each ring) is adhered to.

Customized requirements are welcome!



Part No.	Size (inch)	Inside Length (inch)	Inside Width (inch)	Weight (ibs)	W.L.L. (Single Pull) ibs	Proof Load ibs
RAML0102	1/2	5	2-1/2	0.89	7000	14000
RAML0508	5/8	6	3	1.63	9000	18000
RAML0304	3/4	5-1/2	2-3/4	2.25	12300	28400
RAML0708	7/8	7	3-1/2	3.53	15000	30000
RAML1000	1	7	3-1/2	5.00	24360	48700
RAML1104	1-1/4	8-3/4	4-3/8	9.75	36200	72400
RAML1102	1-1/2	10-1/2	5-1/4	17.12	54300	112200
RAML1304	1-3/4	12	6	26.12	84900	169800
RAML2000	2	14	7	38.00	102600	205200

Grade 80 A-347 Welded Master Link Assembly G100
Grade 80 Master Link Assembly A-345, China G100 Master Link Manufacturer
G80 A-343 Master Link ( Welded), No Flat DIN5688 Master Link Assembly
G100 Forged Master Link, Grade 100 Forged Alloy Steel
G100 Master Link, Grade 100 Forged Alloy Steel
G100 Clevis Master Link, Grade 100 Forged Alloy Steel
G100 MT Master Link Assembly, Grade 100 Forged Alloy Steel
G100 MTC Master Links Assembly, Grade 100 Forged Alloy Steel
G100 WA-S Master Links Assembly, Grade 100 Forged Alloy Steel
G100 WA-S Master Link Assembly, Grade 100 Forged Alloy Steel
G100 WA-S Master Link, Grade 100 Forged Alloy Steel
8007 G80 Master Link Assembly, Grade 100 Forged Alloy Steel 10.8006 G80Master Link Assenbly, Grade 100 Forged Alloy Steel




>>>Company Information:
Welcome to Qingdao Thinkwell Hardware & Machinery Co., Ltd, the one stop provider for rigging hardware ,electric power fittings and trailer hitch accessories.We are always looking to grow and improve on products manufacturing,R&D,domestic selling and overseas exporting, an integrated supply chain management system, marketing management system and quality management system are applied in daily works.Thinkwell's products are wildly exported to USA,Germany,France,Canada,Australia,Middle east,India,Singapore nowadays and serving customers all over the world. We are proud to be the industry pioneer and acknowledged by  customers through dedicating and transforming year after year.

>>>QC

1. Tensile Strength Test is necessary for each batch. Detailed test report and pictures can be provided after order placed.
 2.Surface tolerance, zinc finish, painting finish also be tested according to customers' different requirements.
3.Products' weight is under a reasonable tolerance.
4.Each parts' dimension is always according to the technical drawing and international tolerance standard.
5.Harness testinng also can be provided if you prefer.
6.Salt spray testing is for customers with the most strict quality control requirement, pls pay attention, this testing needs extra testing charges.
7.Chemical anyalisis is rare very much from customers' requirements, can be provided, also needs extra testing charges.
8.Any other testing requirements, feel free to let us know. Will do as we can to support your business always.

>>>Regular package:

carton with pallet.
Pallet included iron pallet, regular wooden pallet and non-fumigation pallet.
Plastic film inside with iron cage is for items with a large cubic, and irregular shape.
Wooden case is high quality to accept more than 1.2ton goods.
Package goods according to customers' different requirements is no problem.( Regular package is for free, customzies package  needs extra  charges according to the truth package cost)

>>>ADVANTAGEOUS:

1.General Raw material comes from tope 10 Steel Companies in China.
2.Sample first before bulk production.
3.QC.Testing report is compulsory before each dispatch.
4.ISO, SGS certify our quality.
5.R&D.customized products is our main development direction.
6.General products order of 1 20ft container was shipped within 25 days.
7. 24 hours on line service for global markets.


>>>FAQ:

1. Can I be your agent?
Yes, welcome to deep cooperation. We have big promotion of THINKWELL brand in the market now. For the details please contact me.
2. Is OEM available?
Yes, OEM is available. We have professional designer to help your brand promotion.
3. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Free for the samples, but you need to pay for the freight.
4. What's your quality guarantee?
We have different kinds of products which can meet different quality standard.
Our QC department will teset products before shipping. We have 100% quality guarantee to customers. We will be responsible for any quality problem.
5. How about the delivery time?
The delivery time is depend on the products and the quantity. But generally, the delivery time for a container is about one month.
6. What's benefit will you bring?
Your client satisfied on the quality.
