• Model NO.：NXL
• Metal：Casting
• Transport Package：Carons
• Specification：ANSI, IEEE, IEC
• Trademark：HAIVOL
• Origin：China
• HS Code：73269090
• Production Capacity：20, 000PCS,Month

Type   Applicable cable 2 cross ction(mm)  Length L1(mm)  Grip strength (kn)  Failureload(KN)   Insulation cover type
NXL-1          50                                                             245              5.16                                      14.50              NXL-95
                     70                                                                                   7.12
                     95                                                                                   9.40
NXL-2         120                                                            255              12.70                                     23.40             NXL-150
                    150                                                                                 15.20
NXL-3         185                                                            300             18.50                                     36.30
                      240                                                                                23.60                                                             NXL-240
NXL-4          22.5-27.5                                                 320              55                                            61                   NXL-4
   •Structure Feature:
1. Choose the unmagnetic chatacter high-intersity oxidate-resistanle aluminium alloy,No waste electric energy
2. Wedged-Locked structure easy-installation
3.An arc embraces the most part,conductor cannot change.Large grip strength
4. No waste electric energy
•Insulation Cover Performance Feature:
1. Withstand voltage: > 18kV keep voltage one minute not breakdown
2. Insulation resistance:> 1.0×1014Ω
3. Environments temperature:-30°C ~90°C
