Double Span Angle Brace for Cross Arm Constructions
L&R ELECTRIC GROUP CO., LTD.- Span Inch：48; 60;72
- Gauge Inch：14;18;22
- Angle Size：L38 X L38 X 5;
- OEM&ODM：Accept
- Transport Package：Export Standard Package or as Client Requirement
- Specification：ISO9001: 2008
Base Info
- Model NO.：Angle Brace Double Span
- Trademark：L&R or according to customer′s requirement
- Origin：Wenzhou, Zhejiang
- Production Capacity：20, 000PCS,Month
Description
Basic Info.
Model NO. Angle Brace Double Span Trademark L&R or according to customer′s requirement Origin Wenzhou, Zhejiang Production Capacity 20, 000PCS/MonthProduct Description
Basic Info.Origin: Yueqing, Wenzhou, Zhejiang, China
Brand Name: as customer's requirement
Model NO.:B0641
Material:Carbon Steel
Finish:Hot DIP Galvanized
Export Markets:Global
Packaging: standard package or cilent's requirment
The double span brace are used to support heavy cross arm construction. Braces are attached to the underside of the cross arm with 1/2 inch machine bolt or lag screw and fastened to the pole with 5/8 inch machine bolt.
| Stock No. | Span Inch (mm) | Gauge Inch (mm) | Angle Size mm | Approximate Shipping Weight Kg. /Pc |
| B0641 | 48 (1,219) | 14 (366) | L40 x L40 x 5 | 4.14 |
| B0644 | 48 (1,219) | 18 (457) | L40 x L40 x 5 | 4.40 |
| B0668 | 60 (1,524) | 18 (457) | L40 x L40 x 5 | 6.85 |
| B0682 | 72( 1,829) | 22 (559) | L40 x L40 x 5 | 8.20 |
Our Services
1. Rich experience in ODM and OEM
2. Excellent One-stop service
3. High Quality Precision Customized forging & Casting services
4. The best price
5. Strict quality control
6. We wormly welcome you come to visit our factory and seek further cooperation
