3/8′ Manille Bow Type Screw Pin Anchor Shackle
Shandong Licheng Link Chain Co., Ltd.- Shape：Bow Shackle
- Usage：Industrial
Base Info
- Color：Zinc Color
- Condition：New
- Size：5mm-50mm
- Function：Fastener
- Brand Name：Ls
- Process：Forged
- Type：Bow Shackles
- Surface：Galvanzied
- Delivery Time：We Could Supply Goods Within 15-25days
- Samples：for Free
- Product Name：European Type Bow Shackle
- Keyword：Bow Shackle
- Transport Package：PP Bags+Gunny Bags, Then on Pallets
- Specification：European Type
- Trademark：LS
- Origin：Shandong, China
- HS Code：7326909000
- Production Capacity：1000000
- Package size per unit product：80.00cm * 60.00cm * 50.00cm
- Gross weight per unit product：1000.000kg
Description
LS EUROPEAN TYPE LARGE BOW SHACKLESWL D d a c r b Weight per 100 pcs kg mm mm mm mm mm mm kg 80 5 5 10 19 8 11 1.9 100 6 6 13 25 10 14 3.4 200 8 8 16 32 12 18 7 320 10 10 19 38 16 20 13 520 12 12 25 51 19 26 24 800 16 16 32 64 28 33 50 1100 20 20 38 76 33 40 80 1500 22 22 44 89 37 50 130 2100 25 25 51 100 40 57 200 3000 28 28 57 115 47 68 300 3500 32 32 64 127 52 73 430 5000 38 38 76 152 63 85 675 7000 45 45 90 180 75 96 1250 8000 50 50 102 200 ,78 108 1750
Shackle are widely used in various industries.
Electric power, metallurgy, petroleum, machinery, railway,chemical
industry,ports, mines, construction.
