Flemish Eye Galvanized Steel Wire Rope Swaging Sleeve
Qingdao Thinkwell Hardware & Machinery Co., Ltd.- Application：Fastening Wire Rope
- Process：Forging, Casting, Stamping
- Treatment：Quenched & Tempered
- Surface：Self-Color, Painted or Galvanized, HDG
- Color：Silver, Self-Color
- Quality：High
Base Info
- Model NO.：Flemish Eye Wire Rope Swaging Sleeve
- Grade：a
- Other：Customized
- Transport Package：Swaging Sleeve with Carton, Bag, Pallet
- Specification：CE ISO9001
- Trademark：Thinkwell
- Origin：China
- HS Code：7326909000
- Production Capacity：Swaging Sleeve 2000PCS Per Day
Description
PART NO.FOR WIRESIZE DIMENSION(inch) MAX.AFTER SWAGE WEIGHT DIMENSIONS Kgs/100Pcs A B D E C (inch) TK01 1/4" 1 0.66 0.31 0.28 0.47 0.57 2.27 TK02 5/16" 1.5 0.91 0.38 0.44 0.62 0.75 6.36 TK03 3/8" 1.5 0.91 0.47 0.39 0.66 0.75 6.36 TK04 7/16" 2 1.22 0.53 0.65 0.85 1.01 15 TK05 1/2" 2 1.22 0.63 0.56 0.91 1.01 13 TK06 9/16" 2.75 1.47 0.7 0.63 1.03 1.24 29 TK07 5/8" 2.75 1.47 0.75 0.63 1.09 1.24 26 TK08 3/4" 3.19 1.72 0.91 0.84 1.28 1.46 40 TK09 7/8" 3.56 2.03 1.03 1 1.53 1.68 60 TK10 1" 4 2.28 1.16 1.13 1.72 1.93 89 TK11 1-1/8" 4.8 2.5 1.28 1.25 1.94 2.13 118 TK12 1-1/4" 5.19 2.78 1.44 1.41 2.16 2.32 161 TK13 1-3/8" 5.81 3 1.56 1.56 2.38 2.52 192 TK14 1-1/2" 6.25 3.25 1.69 1.69 2.63 2.71 227 TK15 1-3/4" 7.25 3.84 1.94 1.97 3.13 3.1 366 TK16 2" 8.5 4.38 2.25 2.25 3.63 3.56 514 TK17 2-1/4" 9.56 5.03 2.5 2.53 4.03 4.12 879 TK18 2-1/2" 10.5 5.5 2.75 2.81 4.5 4.5 1068 TK19 2-3/4" 11.5 5.75 3 3.09 4.75 4.7 1271 TK20 3" 12 6 3.25 3.38 5 4.96 1335 TK21 3-1/4" 13 6.5 3.86 3.54 5.43 5.37 1650 TK22 3-1/2" 14 7 3.88 3.94 5.84 5.77 2106 TK23 3-3/4" 15 7.5 4.06 4.25 6.31 6.23 2497 TK24 4" 16 8.13 4.38 4.5 6.81 6.69 3087 TK25 4-1/2" 18 9.13 4.88 5.06 7.66 7.45 4540 TK26 5" 20 10.52 5.5 5.63 8.73 8.28 6600 TK27 6" 24 12.54 6.5 6.75 10.2 9.93 12300
