Strain Clamps (NLL series)
Wenzhou Ziyong Electrical Co., Ltd.- Usage：Heavy Duty Clamp
- Standard：Standard
- Condition：New
- Tension Clamp：Clamp
- Transport Package：Standard Package
- Specification：as you requested
Base Info
- Model NO.：NLL series
- Trademark：JMA
- Origin：China
- HS Code：8538900000
- Production Capacity：300000PCS,Month
Description
U-boltRated Failure Load
(KN) Weight (kg) C M M Number NLL-1 5.0-10.0 18 16 12 2 40 0.83 NLL-2 10.1-14.0 18 16 12 2 40 1.09 NLL-3 14.1-18.0 27 16 14 3 70 2.21 NLL-4 18.1-23.0 30 18 14 3 90 2.86 NLL-5 23.0-29.0 36 22 16 4 120 5.70 NLL-6 25.9-32.7 42 22 18 4 120 6.55
2.The curvature radius of the tensioning clamp is not less than 8 times the diameter of the installed wire.
3.When the bolt type tensioning clamp is used for steel core aluminum stranded wire, the wire can be wrapped with aluminum and interline, and the outer diameter of the wire includes wrapping material.
4.If used on overhead insulated conductors, please peel off the insulating layer and use it.
Service
Choose our products! You'll get
1) Good quality guarantee (2 years)
2) Factory direct prices
3) On time delivery
4) Free sample
5) Professional technology support
Strict quality controls have been taken to ensure that you'll get reliable products.
a. Material checks before production.
b. Random inspection during production.
c. Inspection before the shipment.
Our products fully comply with well recognized standards such as IEC, BS, ANSI.
FAQ:
1. Q: Do you have a catalog? Can you send me the catalog to have a check of all your products?
A: Yes, We have product catalog. Please contact us, we'll send our catalog by E-mail.
2 Q: I can't find the product on your catalog, can you make this product for me?
A: Our catalog shows most of our products but not all. If you couldn't find it, let us know the specification of your requirements, it usually takes 20-30 days for us to design and make new moulds which match your requirements.
3 Q: What's your payment term?
A: The price FOB Ningbo under payment term is 50% T/T in advance and the balance before shipment.
Please scan the QR Code below, and you can learn more about the company's information.
