Oh ACSR AAAC Cable Suspension Anchor Clamp Line Hardware
L&R ELECTRIC GROUP CO., LTD.- Usage：Power Line Fittings
- Structure：Suspension Clamp
Base Info
- Model NO.：XGF HANG-DOWN TYPE
- Standard：Standard
- Condition：New
- Color：Silver White
- Bolts Finish：Galvanizing
- Application：Power Line Fittings
- Conductor：AAAC, ACSR
- Transport Package：Export Standard Package
- Specification：ISO9001: 2008
- Trademark：L&R
- Origin：Wenzhou, Zhejiang
- Production Capacity：20, 000PCS,Month
- Package size per unit product：50.00cm * 40.00cm * 30.00cm
- Gross weight per unit product：21.000kg
Description
Approximate weightL C R H M CGH-2 5.1-12.5 167 22.5 9.25 63.5 16 40 1 CGH-3 12.4-17.0 202.5 22.5 11.75 62 16 40 1.5 CGH-4 19.0-23.5 225 29 13 73.5 16 40 2.3 CGH-5 24.2-28.0 263 37.8 16.75 83.5 16 60 3 CGH-6 25.0-35.0 216 35 17.5 68 16 60 3.6
Application:
Mainly used to fix the conductor to the insulator string, or suspend ground wire on tangent towers, also can be used to support the transposed conductor to transposition tower, or attach jumper to the strain tower or the angle tower.
