• Model NO.：428-
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. 428- Production Capacity 1000PCS/Month

Product Description

Angle Plate, Angle Table
1. We can supply all kinds of Angle Plate, Angle Table to satisfy clients' needs.
2. We are able to manufacture Angle Plate, Angle Table according to clients' drawings.
3. Our Angle Plate, Angle Table are acknowledged and very popular in the international market.
4. We are willing to provide clients with our samples of Angle Plate, Angle Table if being requested.
5. Welcome to send detailed enquiries with our model number and your quantity of Angle Plate, Angle Table to us to begin our business.

Plate Size	Height	T-Bolt
(In)	(In)	(In)	Model No.
5x7	3-7/8	3/8	200-1105
7x10	5-3/16	7/16	200-1110
9x12	6-7/16	7/16	200-1112
10x15	7-3/8	5/8	200-1115
12x24	8-1/8	5/8	200-1124

	No. of	Machined	Grounded
Size	Ribs	Model No.	Model No.
2x2x2' '	1	418-4310	418-4410
3x3x3' '	1	418-4315	418-4415
4x4x4' '	2	418-4320	418-4420
5x5x5' '	2	418-4325	418-4425
6x6x6' '	2	418-4330	418-4430
8x8x8' '	2	418-4335	418-4435
10x10x10' '	2	418-4340	418-4440
12x12x12' '	2	418-4345	418-4445

			Webbed	Webbed	Webbed	Webbed
Dimensions	Dimensions	Dimensions	Machined	Grounded	Machined	Grounded
A	B	C	Model No.	Model No.	Model No.	Model No.
3"	2-1/2"	2"	418-4510	418-4612	418-4712	418-4812
3-1/2"	3"	2-1/2"	418-4515	418-4617	418-4717	418-4817
4-1/2"	3-1/2"	3"	418-4520	418-4622	418-4720	418-4822
6"	5"	4-1/2"	418-4525	418-4627	418-4725	418-4827
7"	5-1/2"	4-1/2"	418-4530	418-4632	418-4730	418-4832
8"	6"	5"	418-4535	418-4637	418-4735	418-4837
9"	7"	6"	418-4540	418-4642	418-4740	418-4842
10"	8"	6"	418-4545	418-4647	418-4745	418-4847
12"	9"	8"	418-4550	418-4652	418-4750	418-4852
