• Model NO.：BS-BC001
• Delivery Term：Fob
• Sample：Free
• Payment：T,T Transfer
• Transport Package：Bulk Carton Packing
• Specification：M8-M12
• Trademark：No
• Origin：China
• HS Code：7318150090
• Production Capacity：500000PCS Per Month

Basic Info.

Model NO. BS-BC001 Delivery Term Fob Sample Free Payment T/T Transfer Transport Package Bulk Carton Packing Specification M8-M12 Trademark No Origin China HS Code 7318150090 Production Capacity 500000PCS Per Month

Product Description

Beam Clamp

1. Material: Cast Malleable Steel with hardened cup point set screw and jam nut;
 2. Finish: Electro-galvanized finish for enhanced corrosion protection,
Available in hot dip galvanized fi nish (special order);
 3. Features: May be used on top or bottom flange of the beam. Beveled lip allows hanging from top flange where clearance is limited. may be installed with the set screw in the up or down position. Offset design permits unlimited rod adjustment by allowing the rod to be threaded completely through the clamp. The rear window design permits inspection of thread engagement;
 4. Function: For attachment to structural shapes requiring wider throat especially under roof with bar joist construction. This clamp may be used with the set screw in the up or down position;
 5. Note: Do not over tighten set screw.


Product information:
*Use this clamp to secure threaded wire rings to metal surfaces
*Easy, efficient management of drop cable

Mallable Iron Rod Support Beam Clamp - Strong, durable Rod Support Beam Clamp.
Used with Conduit Hangers, Bridle Rings & Drop Rods 1/4" up to 1/2"
Tapped for Rods - bottom and back on all sizes
Malleable Iron Zinc Plated

Materials Carbon Steel, Malleable Iron and Forged Steel are used in the manufacturing of beam clamps and accessories. Stainless steel and other materials are available.
Finishes The standard finishes for mechanical supports are plain steel (oil coated) sometimes referred to as black and Electro-Galvanized Zinc (ASTM B633 SC3). Hot-Dip Galvanized After Fabrication (ASTM A123), Red Primer, Plastic Coating and DURA GREEN™. Other special coatings are available upon request.
Note: Due to the design of some products, (threads, connecting hardware, swivels, etc.) items may or may not be uniformly coated with special finishes. In some cases, the hanger itself may be coated, however, the hardware may be supplied Electro-Plated, copper plated, or in stainless steel. Recommended Set screw Torque (unless otherwise specified) 1/4"-20 3/8"-16 1/2"-13 5/8"-11 3/4"-10 4 ft/lbs (5 Nm) 5 ft/lbs (7 Nm) 11 ft/lbs (15 Nm) 21 ft/lbs (28 Nm) 34 ft/lbs (46 Nm) Over torqued set screws will damage beam clamps in this section. We are aware that torque wrenches are not used or not available in many instances. In the absence of a torque wrench, the set screw should be finger tightened to the I-beam and then an additional 1/4 to 1/2 turn applied to the set screw. Approvals (as noted) Items in this section are Underwriters Laboratories Listed, Factory Mutual Approved, and comply with Federal Specification WW-H-171E & A-A-1192A or Manufacturers Standardization Society ANSI/MSS SP-69 & SP-58.
