• Model NO.：Long Link Chain for Marine
• Color：Silver, Black
• Application：Mooring or Ships
• Surface：Galvanized, Black, HDG
• Process：Welded
• Grade：30,43,70,80,100
• Quality：High
• Testing：Qualified
• Other：Customized
• Factory：Yes
• Sample：Yes
• Store：Yes
• Transport Package：Anchor Chain with Carton, Bag, Pallet
• Specification：CE ISO9001
• Trademark：Thinkwell
• Origin：China
• HS Code：7326909000
• Production Capacity：Anchor Chain 2000PCS Per Day

Grade80 Alloy ChainSize dInside Length pInside WidthWorking Load (Max)Proof Test (Min)Breaking ForceWeight Per 100ftWeight Per Metermmmmmmkgskn(Min) knkgskgs6188.7115022.54524.30.872210.5157030.861.6331.0882412205040.380.643.51.4392712250050.810254.81.8103014.532006312667.62.221339195400107214113.63.73138224540010721488.42.91648238200161322170.35.5819572611200227454243.8820602812500250500274.39226629.51500030060033210.92678352000040080046315.2  DIN 5685AC Short /Long Link ChainSIZE dINSIDE LENGTH pOUTSIDE WIDTH bWEIGHT PER 100MWORKING LOADBREAKING LOADGRADEMMMMMMKGNN212875001250A226C2.51410117502000A2410C3161216.511202800A2615C419163020005000A3227C521205031507750A3543C6242473450011500A4263C72828100600015000A4986C83232130800020000A52110C936361651000025000A59141C1040402051250031000A65175C1144442501500038000A72211C1248482901800045000A78255C1352523452120053000A82295


Size d	Outside Length p+2d	Outside Width b	Breaking Load	Proof Load	Weight
mm	mm	mm	min,kn	min,kn	kg/m
8	40	27	23.67	11.8	1.39
9	45	30	29.96	14.91	1.76
10	50	34	36.98	18.44	2.16
11	55	37	44.75	22.32	2.65
12.5	63	43	57.58	28.81	3.4
14	70	48	72.49	36.1	4.26
16	80	54	94.68	47.21	5.56
18	90	60	113.3	56.48	7.15
19	95	64	133.5	66.58	7.97
20	100	68	155.39	77.5	9.14
22	110	75	179	89.27	10.52
24	120	81	213	106.23	12.52
26	130	88	278	139	14.8
28	140	95	321	225	17.17
32	160	108.8	417	291	22.43
34	170	115.6	544.74	272.37	25.32
36	180	122.4	610.7	305.35	28.3
38	190	129	680.45	340.23	31.6
40	200	136	753.96	376.98	35.04
42	210	143	831.24	415.62	38.65
44	220	150	912.29	456.15	42.4
46	230	156.4	997.11	498.56	46.34
48	240	163.2	1085.7	542.85	50.46
50	250	170	1178.06	589.03	54.75

1. Can I be your agent?
Yes, welcome to deep cooperation. We have big promotion of THINKWELL brand in the market now. For the details please contact me.
2. Is OEM available?
Yes, OEM is available. We have professional designer to help your brand promotion.
3. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Free for the samples, but you need to pay for the freight.
4. What's your quality guarantee?
We have different kinds of products which can meet different quality standard.
Our QC department will teset products before shipping. We have 100% quality guarantee to customers. We will be responsible for any quality problem.
5. How about the delivery time?
The delivery time is depend on the products and the quantity. But generally, the delivery time for a container is about one month.
6. What's benefit will you bring?
Your client satisfied on the quality.
