1.0ton Non-Sideshifting Bale Clamp (G04B10)
Shanghai Hytger Industry & Trade Co., Ltd.- Material：Metal
- Usage：Heavy Duty Clamp
- Structure：G Clamp
- Standard：Standard
- Condition：New
- Brand：Hytger
Base Info
- Model NO.：G04B10
- Name：1.0ton Non-Sideshifting Bale Clamp (G04b10)
- Capacity：1000,500 mm
- Opening：490-1590 mm
- Effective：133mm
- Horizontal：115mm
- Weight：285kgs
- Vertical：270mm
- Arm：900mm
- Transport Package：Seaworthy Packing
- Specification：CE, SGS, ISO
- Trademark：SHYTGER
- Origin：Shanghai, China
- HS Code：84272090
- Production Capacity：3000units,Year
Description
Model Capacity/
Load Center Opening
Range
D Effective
Thickness
C Horizontal
Center
of Gravity
CGH Weight Vertical
Center
of Gravity
CGV Arm
Length
L Arm
Height
A
Frame
Width
B
Mounting
Class ( kg/mm) (mm) (mm) (mm) (kg) (mm) (mm) (mm) (mm) G04B10-159A11 1000/500 490-1590 133 115 285 270 900 350 850 2 G04B10-160A01 500-1600 108 275 800 G04B15-179A42 1500/500 490-1790 139 280 445 270 1200 400 1040 G04B15-180A22 500-1800 405 1000 G04B22-179A22 2200/500 490-1790 147 340 585 265 1200 400 1040 2 G04B22-179B42 3 G04B22-180A22 610-1520 335 535 1000 2 G04B22-180B22 3 G04B20-200A42 2200/500
550-2000
147 340 615 265 1200 400 1140 2 G04B20-200B42 3 G04B20-200A53 350 685 1350 450 2 G04B20-200B53 3 G04B20-201A22 560-2010 335 565 1000 400 2 G04B20-201A22 3
Q : 1. Can I have a sample order?
A : Yes,we welcome sample order to test and check quality.Mixed samples are acceptable.
Q : 2. What is the lead time?
A : Sample needs 1-3 days,mass production needs 7-15days,also according to the order volume.
Q : 3. Can you accept mixed batch of different products?
A : Yes,we are support different product mix wholesale.
Q : 4. How do you ship the goods and how long does it take arrive?
A : For sample order ,we usually ship by DHL,UPS,FedEx or TNT.It usually takes 3-5 days to arrive.
Q : 5. Can you provide container packed in wooden cases if I order more products?
A : Yes,we are can provide a set of wooden packaging products,but only in big quantity.
Q : 6. We want to visit your company?
A : No problem,we are a production and processing enterprises,look forward to your arrival and we will lead you to visit our factory and processing factory.
Standard Products: All Grip Attachments as listed are standard products, special or custom products are available according to user's requirements, please contact our Sales Dept.
Forklift Truck: Normally, the forklift can supply sufficient flow to operate and attachment , please do not attempt to exceed the maximum flow and pressure. Do use the recommend data. If there's special needs, please contact Girp.
Capacity: To determine the working capacity for each application, the residual capacity must be calculated , taking into consideration the load and operating conditions.
Mounting Class: Mounting Class conforms to Standard ISO type, attachments could be mounted on forklift that have ISO hook type carriage bars. For any other non-standard mounting , please cont Grip.
Accessories: Free angle couplings could be sent with attachments , used to connet attachment with forklift, M18*1.5. Please contact if special connection type is required.
