- Model NO.：Preformed dead end Grip Tension Clamp
- Size：Can Be Ordered
- Transport Package：Export Standard Package or as Client Requirement
- Specification：ISO9001: 2008
- Trademark：L&R or according to customer′s requirement
- Origin：Wenzhou, Zhejiang
- Production Capacity：20, 000PCS,Month
Industry Standard Type | Standard Model | Applicable Conductor Diameter (mm) | Applicable Conductor Model GB1179-1983 | Clamp Length (mm) | Weight (kg) | Matched Fitting |
| Min | Max | ACSR LGJ/LGJF |
| NL-35/6 | DN1112 | 7.35 | 8.26 | 35/6 | 625 | 0.2 | TC-07 |
| NL-50/8 | DN1112 | 7.35 | 8.26 | 35/6 | 685 | 0.2 | TC-07 |
| NL-70/10 | DN1115 | 10.40 | 11.68 | 70/10 | 740 | 0.3 | TC-07 |
| NL-50/30 | 50/30 | TC-07 |
| NL-70/40 | DN1117 | 13.12 | 14.66 | 70/40 | 880 | 0.6 | TC-07 |
| NL-95/15 | 95/55 | TC-07 |
| NL-95/20 | 120/25 | TC-07 |
| NL-120/7 | 150/8 | TC-07 |
| NL-120/20 | DN1118 | 14.67 | 16.59 | 120/20 | 890 | 0.8 | TC-07 |
| NL-95/55 | 95/55 | TC-10 |
| NL-120/25 | 120/25 | TC-07 |
| NL-150/8 | 150/8 | TC-07 |
| NL-150/20 | DN1119 | 16.60 | 18.77 | 150/20 | 1020 | 1.1 | TC-07 |
| NL-120/70 | 120/70 | TC-10 |
| NL-150/25 | 150/25 | TC-07 |
| NL-150/35 | 150/35 | TC-07 |
| NL-185/10 | 185/10 | TC-07 |
| NL-185/25 | DN1120 | 18.78 | 21.26 | 185/25 | 1160 | 1,7 | TC-07 |
| NL-185/30 | 185/30 | TC-07 |
| NL-210/10 | 210/10 | TC-07 |
| NL-185/45 | 185/45 | TC-10 |
| NL-210/25 | 210/25 | TC-10 |
| NL-210/35 | 210/35 | TC-10 |
| NL-210/50 | 210/50 | TC-10 |
| NL-240/30 | DN1121 | 21.27 | 24.05 | 240/30 | 1275 | 2,3 | TC-10 |
| NL-240/40 | 240/40 | TC-10 |
| NL-240/55 | 240/55 | TC-10 |
| NL-300/15 | 300/15 | TC-07 |
| NL-300/20 | 300/20 | TC-12 |
| NL-300/25 | 300/25 | TC-12 |
| NL-300/40 | 300/40 | TC-12 |
| NL-300/50 | DN1122 | 24.06 | 27.20 | 300/50 | 1425 | 3.0 | TC-12 |
| NL-300/70 | 300/70 | TC-12 |
| NL-400/20 | 400/20 | TC-12 |
| NL-400/25 | 400/25 | TC-12 |
| NL-400/35 | 400/35 | TC-12 |
Our Services
1. Rich experience in ODM and OEM
2. Excellent One-stop service
3. High Quality Precision Customized forging & Casting services
4. The best price
5. Strict quality control
6. We wormly welcome you come to visit our factory and seek further cooperation
