• Model NO.：Din 1142 Galvanized U Bolt Clamp Wire Rop Clip
• Test：Qualified
• Other：Customized
• Transport Package：Wire Rope Clips with Carton, Bag, Pallet
• Specification：CE ISO9001
• Trademark：Thinkwell
• Origin：China
• HS Code：7326909000
• Production Capacity：Wire Rope Clips 2000PCS Per Day

Basic Info.

Model NO. Din 1142 Galvanized U Bolt Clamp Wire Rop Clip Test Qualified Other Customized Transport Package Wire Rope Clips with Carton, Bag, Pallet Specification CE ISO9001 Trademark Thinkwell Origin China HS Code 7326909000 Production Capacity Wire Rope Clips 2000PCS Per Day

Product Description

Galvanized Malleable Steel DIN 1142 Wire Rope Clips

Material:  Malleable steel
U-bolt: Mild steel
Standard: EN 13411-5 Type A
Formerly DIN 1142
Finish: Electro-galvanized or hot-dip galvanized
Packing: Bag, carton, pallet

Customized requirements are welcome!

Origin: China
FOB Port: Qingdao
Lead time: 15~45 Days
Main export market: Europe, Middle East, US, Australia, Canada, etc
Standard: CE, ISO

Advantages:

1.Rich experience for international business
2.Prompt delivery
3.Quality control
4.Small orders are acceptable
5.Strong ability for R&D

Din1142 and Din741 Wire Rope Clip
US Type Wire Rope Clip
Stainless Steel Wire Rope Clip
Wire Rope Grip

QingdaoThinkwell also manufacture hooks, shackles, turnbuckles, wire rope clips, load binders and other rigging hardware accessories.


Diameter Wire Rope	Diameter Bow (a)	Length Bow (b)	Width Inside (c)	Length Thread (d)	Length Base (e)	Thickness Base (f)	Height Base (g)	Weight per 100pcs
mm	mm	mm	mm	mm	mm	mm	mm	kg
3	4	20	9	12	21	10	10	1.4
5	5	24	11	13	23	11	10	1.5
6	5	28	13	15	26	12	11	2.1
8	6	34	16	19	30	14	15	4.1
10	8	42	19	22	34	18	17	6.8
11	8	44	20	22	36	19	18	7.2
13	10	55	24	30	42	23	21	13
14	10	57	25	30	44	23	22	13.5
16	12	63	29	33	50	26	26	21
19	12	75	32	38	54	29	30	28
22	14	85	37	44	61	33	34	40
26	14	95	41	45	65	35	37	44
30	16	110	48	50	74	37	43	66
34	16	120	52	55	80	42	50	85
40	16	140	58	60	88	45	55	104
