Xgf Suspension Clamp (hang-down type)
Wenzhou Ziyong Electrical Co., Ltd.- Material：Aluminium
- Usage：Heavy Duty Clamp
- Structure：G Clamp
- Standard：Standard
- Condition：New
- Brand：Jma
Base Info
- Model NO.：XGF-5X
- Aluminum Alloy Suspension Clamp：Power Cable Suspension Clamp
- Size：Various Size Available
- Transport Package：Standard Export Packaging
- Specification：CE
- Trademark：JMA
- Origin：Chongqing, China
- HS Code：8538900000
- Production Capacity：50000 PCS
Description
Catalog No.Conductor Dia.
(mm) Dimensions (mm) Rated Failure
Load (KN) Weight
(kg) H L R C M JMA-3 12.4-17.0 53 180 10 20 16 40 1.5 JMA-4 19.0-23.5 74 226 12 28 16 40 2.3 JMA-5 23.0-32.0 68 216 15 35 16 60 3.0 JMA-6 25.0-35.0 68 216 17.5 35 16 60 3.6 JMA-8 48.0-53.0 97 300 27 56 20 60 5.5
Application
Single or double anchor on a pole
The anchoring clamp is suitable for insulated low-voltage ABC cable. It is also suitable for multiple conductors. It has easy installation and perfect insulated function.
One Core Anchor clamps are design to anchor self supporting LV. ABC from 2 to 4 cores, the wedge
Can be self-adjusting.
Only or steel sheets and aluminum alloy coverd and making it easy to install the clamp to any kind of anchoring point.
Our Services
1. We are specialized in manufacturing overhead power line fittings.
2. Many years manufacture experience.
3. Certificates: ISO9001.
4. High quality with competitive price.
5. Domestic and Overseas markets.
6. Well equipped with complete facilities.
7. Strict quality control and excellent after-sales service.
