• Model NO.：IPC3.4
• Name：Insulation Piercing Clamps
• Teeth Material：Aluminum, Brass, Copper
• Screw Material：45# Steel
• Piercing Depth：2.5-3.5mm
• Type：Piercing Connector
• Main Line：16-95 Sqmm
• Branch Line：4-35(50) Sqmm
• Casing Material：PA66
• Sample：Free
• Head Type：Round
• Transport Package：24PCS,Carton
• Specification：Insulation Piercing Connectors
• Trademark：GENTAI
• Origin：China
• HS Code：8538909090
• Production Capacity：300000PCS Per Year

Basic Info.

Model NO. IPC3.4 Name Insulation Piercing Clamps Teeth Material Aluminum, Brass, Copper Screw Material 45# Steel Piercing Depth 2.5-3.5mm Type Piercing Connector Main Line 16-95 Sqmm Branch Line 4-35(50) Sqmm Casing Material PA66 Sample Free Head Type Round Transport Package 24PCS/Carton Specification Insulation Piercing Connectors Trademark GENTAI Origin China HS Code 8538909090 Production Capacity 300000PCS Per Year

Product Description

Product description:

Insulation piercing connector is mainly suitable for the connection of the overhead insulation conductor, branch connection and grounding protection, It is used for the voltage which is 20KV, 10KV and 1KV and below. Applicable for Al-Cu conductor, different diameter wire connection, and equal diameter wire butt, and is suitable for the transition of copper aluminum insulation conductor link.


Main function and features:
1.Easy installation,No need to strip the cable insulation cover,
2.Piercing connector,special nut and torque nut.To ensure good electrical connection without damage wires.
3. Resistance reduced by 30% Heat cycle curve is more stable.
4.Good Insulation,It passed the power frequency withstand voltage and underwater withstand voltage performance test without any special treatment.Sealing structure and with insulation grease.wetpoof,waterproof,anti-corrosion,extend the service life of insulated conductor and clamp.



FAQ:

Q1:Are you a trading company or manufacturer?
We are professional manufacturer for distribution board and meter socket . also we supply of different electrical and electronic items
Q2: why will you choice us :
more than 10years of professional teams will give you good quality products ,good service ,and reasonable price
Q3:Can we have our logo or company name to be printed on your products or the package?
 We offer OEM , ODM . our designer can make special design for you .
Q4: Is the MOQ fixed?
The MOQ is flexible and we accept small order as trial order.
Q5:Can I have a visit to you before the order?
you are welcome to visit our company ..
our company is only one hour by Air from shanghai
