Metal Shackle Clevis Adaptors Clamp

Zhejiang Haivo Electrical Co., Ltd.

Material：Metal
Usage：Heavy Duty Clamp
Structure：Strain
Standard：Standard
Condition：New
Brand：Haivol

Base Info

Model NO.：U type
Metal：Casting
Transport Package：Carons
Specification：ANSI, IEEE, IEC
Trademark：HAIVOL
Origin：China
HS Code：73269090
Production Capacity：20, 000PCS,Month

Description

Anchor shackles are used to attach hardware to the tower pad.Back to back anchor shackles are commonly used at the tower
attachment point to orient the plane of the tower plate and he balance of the insulator hardware.
•Material:
Body: Galvanized steel
Bolt and nut: Galvanized steel
Split pin: stainless steel
•specifications:typeDimensions(mm)ABD1D2WTLDIron-122921618406130DIron-2221171618406111DIron-3221051618406130
Metal Shackle Clevis Adaptors Clamp

Pre：Anchor Shackles (U type) Clevis Adaptors Clamp
Next：Ball Eyes Fitting
