U. S Type G43 Alloy Lifting Welded Link Chain
Weifang First Rigging Co., Ltd.- Usage：Transmission Chain, Drag Chain, Conveyor Chain
- Material：Alloy
- Surface Treatment：Polishing
- Feature：Heat Resistant
- Chain Size：1,2"*3,32"
- Structure：Welded Chain
Base Info
- Model NO.：G43
- Color：Multi-Colored
- Process：Welded+Heat Treatment+Surface Treatment
- Certificate：ISO9001
- Specificate：10*40-48*152
- Lead Time：Within 15 Works Days After Receive Deposit
- Transport Package：Iron Drum and Pallets
- Specification：alloy steel
- Trademark：FR
- Origin：China
- HS Code：73158200
- Production Capacity：800tons,Year
Description
The sample is free,the freight should on your account before
your first order
1.Decoration;Protection;Lifting;Traction
2.Fishing&boat chain;Mine chain; Cement lifting round chain
| size d*p(mm) | min b | max b | kg/m | working load (Kn) | testing load (Kn) | breaking load (Kn) |
| 6*18 | 7.5 | 21 | 0.79 | 11 | 27 | 45.2 |
| 7*21 | 9 | 24.5 | 1.07 | 15 | 37 | 61.6 |
| 8*24 | 10 | 28 | 1.38 | 20 | 48 | 80.4 |
| 9*27 | 11.5 | 30 | 1.9 | 24.5 | 61 | 102 |
| 10*30 | 12.5 | 35 | 2.2 | 32 | 76 | 125 |
| 12*36 | 15.5 | 42.2 | 3.3 | 49 | 117 | 196 |
| 13*39 | 16.3 | 46 | 3.8 | 50 | 128 | 214 |
| 14*42 | 18 | 49 | 4.13 | 63 | 150 | 250 |
| 16*48 | 20 | 56 | 5.63 | 80 | 192 | 320 |
| 18*54 | 23 | 63 | 6.85 | 100 | 246 | 410 |
| 20*60 | 25 | 70 | 8.6 | 125 | 300 | 500 |
| 22*66 | 28 | 77 | 10.5 | 153 | 366 | 610 |
| 24*72 | 32 | 82 | 12.78 | 180 | 432 | 720 |
| 26*78 | 35 | 91 | 14.87 | 213 | 510 | 650 |
| 30*90 | 38 | 105 | 19.6 | 283 | 678 | 1130 |
| 32*96 | 40 | 106 | 22.29 | 322 | 772 | 1289 |
| 34*102 | 46.5 | 121.5 | 25.5 | 363 | 870 | 1450 |
| 36*108 | 49.5 | 128.5 | 31 | 407 | 978 | 1630 |
| 38*114 | 52 | 136 | 32 | 453 | 1086 | 1810 |
| 42*126 | 55.5 | 144.5 | 38.6 | 554 | 1332 | 2200 |
SHIPPING & DELIVERY
Usually packed in plastic bags, and then in export carton, high quality pallets ;According to your requirements.
Delivery Detail: Usually 25-30 working days after receiving your advance payment.
Bulk packing
Packed in wooden cases
Packed in Iron drum, then in pallets
According to your requirements
Delivery Detail:
Usually 25 days after receiving your advance payment.
Company Profile
Founded in 1998, Weifang First Rigging Co., Ltd, formerly known as Changle Chain Factory, is located in Changle Country of Shandong Province known as "The Gem City of China", and specializes in producing and marketing chain and rigging related products at home and abroadOur company has independent import and export operating rights, and can handle the certifications of CCS, LR, DNV and other famous classification societies for products. Our products are sold to dozens of countries such as Europe, America ano Middle East as well as more than ten provincial and municipal regions in China, and are widely applied to the fields of ships, steel, petrochemical industry, coal mine, etc.In the principle of "Quality-honoring & Promise-keeping", our company meets the requirements of all the customers through service innovation, changes the original production state through technical innovation, improves the product quality through process innovation, and continuously goes to standardization, elaboration, process and scientification through the business thought of constant innovation. Absolute sincerity will move a heart of stone. Our company is willing to cooperate with domestic and foreign new/old customers in utmost sincerity, to create a common future!
FAQ
1.Are your manufacturer or Trading Company?
First rigging is professional manufacturer, more than 20 years experience.
2. What products do you supply?
1) Lifting link chain, Coal Mining chain
2) Round Master link
3) Other related products
3.What is your lead time?
Usually 25-30 working days after receiving your advance payment.
4. How do I receive the goods ?
FOB, CFR, CIF are most commonly used trade terms.
5.How do I pay?
TT(Telegraphic Transfer),30% payment in advance, 70% balance before shipment.
Website: rigging.en.made-in-china.com
