1.0-4.0mm Automatic Compression Coiler CNC Spring Coiling Machine

Dongguan Hua Yi Da Spring Machinery Co., Ltd.
  • Function：Pressed, Phonation, Buffer, Drive, Restoration, Measurement, Forming
  • Material：Stainless Steel
  • Usage：Industrial, Auto, Furniture, Motorcycle, Home Appliance, Seat
  • Load Type：Bend
  • Production Process：Cold Roll
  • Shape：Cylinder

Base Info

  • Model NO.：HYD-340
  • Axis Count：3
  • Wire Size Range：1.0-4.0mm
  • Max Od：40mm
  • Maximum Wire Length：Unlimted
  • Maximum Reel Speed：120meter,Min
  • Maximum Wire Directive：0.01mm
  • Outer Diameter Settin Range：≤65.00mm
  • Yield Per Minute：≤400PCS
  • Machine Weight：1200kg
  • Machine Size：1200*850*1650mm
  • Transport Package：Standard Wooden Box
  • Specification：1200*850*1650mm
  • Trademark：HYD
  • Origin：Dongguan
  • HS Code：8463300000
  • Production Capacity：300 PCS,Years

Description

HYD-340 compression spring machineModel                                         HYD-340Diameter                                      1.0-4.0mmMaximum wire length                           UnlimtedThe direction of the reel                      Right and Left HandMaximum reel speed                           120 Meter/minMaximum wire directive                          0.01mmOuter diameter setting range                     ≤65.00mmYield per minute                                ≤400pcsWire feeding servo motor                         5.5kwOutside diameter of the servo                     5.5kwPitch servo                                     1.0kwMachine size                                 1200*850*1650mmMachine weight                                 1200kg

HYD Services:
1. Free training is provided in HYD production base.Pictures and video of the machine operation will be sent for confirmation before shipment.

2. The professional and patient consulting service will help you find the suitable solution.

3. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.

4. HYD provide technical support by email and phone,technicians will be available at your side if necessary.

5. Spare parts will be freely supplied during the guarantee period(one year), original cost after this period.


FAQ
1. Q: What information will be helping to get an accurate quotation from us?
  A: The customer should provide the related drawings, pictures, industrial voltage, planned output, technical requirements, etc

2. Q: What is the power supply of the machine?
  A:  The standard power supply in China is 380V, 3P, 50Hz. We also can customized as per requirement.

3. Q: What is the payment term
  A: The payment term is 30% deposit as PO confirmation ,and 70% should be finished before the shipment.We also accept other payment term.

4. Q: What is the delivery time?
  A: Normally the delivery time of the machine is 30 days after receiving deposit.But it depends on machine model.Some of them could be shipped within 10 days.

5. Q: What is the guarantee period of the machine?
  A: The guarantee period is one year from the date of B/L.
