Factory Supplied Nacm90 Standard Chain
Weifang First Rigging Co., Ltd.- Usage：Drag Chain, Nacm90 Chain
- Material：Alloy
- Surface Treatment：According to Your Requirements
- Feature：Heat Resistant
- Chain Size：4mm-25mm
- Structure：Welded Chain
Base Info
- Model NO.：FST-ASTM-05
- Color：According to Your Requirements
- Product Name：Factory Supplied Nacm90 Standard Chain
- Process：Welded+Heat Treatment+Surface Treatment
- Certificate：ISO9001
- Transport Package：Packed in Wooden Case,Iron Drum, Then in Pallets
- Specification：4mm-25mm
- Trademark：First Rigging
- Origin：Shandong, China
- HS Code：73158200
- Production Capacity：150ton,Month
Description
SizeMaterial Diameter Working Load Limit Proof test (min) Min Breaking(force) Inside Length(max) Inside Width(min) MM IN MM IN KG LBS KG LBS KG LBS MM IN MM IN 4 1/8 4 0.156 170 375 360 800 700 1600 23.9 0.94 6.4 0.25 5.5 3/16 5.5 0.217 365 800 720 1600 1430 3200 24.8 0.98 7.7 0.30 7.0 1/4 7.0 0.276 580 1300 1160 2600 2310 5200 31.5 1.24 9.8 0.38 8.0 5/16 8.0 0.331 860 1900 1510 3400 3020 6800 32.8 1.29 11.2 0.44 10.0 3/8 10.0 0.394 1200 2650 2360 5300 4710 10600 35.0 1.38 14.0 0.55 13.0 1/2 13.0 0.512 2030 4500 3980 8950 7960 17900 45.5 1.79 18.2 0.72 16.0 5/8 16.0 0.630 3130 6900 6030 13600 12060 27200 56.0 2.20 20.0 0.79 20 3/4 20.0 0.787 4800 10600 9430 21200 18850 42400 70.0 2.76 25.0 0.98 22.0 7/8 22.0 0.866 5810 12800 11410 25600 22810 51200 77.0 3.03 27.5 1.08 25 1 26.0 1.02 8140 17900 15910 35800 31820 71600 90.9 3.58 31.7 1.25 Material Diameter Working Load Limit Proof test(min) Min Breaking(force) Inside Length(max) Inside Width(min) MM IN MM IN KG LBS KN LBS KN LBS MM IN MM IN 7 1/4 7 0.276 1180 2600 16.6 3750 33.1 7500 31.5 1.24 9.8 0.38 8 5/16 8 0.315 1770 3900 21.6 4900 43.2 9700 32.8 1.29 11.2 0.44 10 3/8 10 0.394 2450 5400 33.8 7600 67.6 15200 35 1.38 14 0.55 13 1/2 13 0.512 4170 9200 57.1 12900 114.2 25700 45.5 1.79 18.2 0.72 Material Diameter Working Load Limit Proof test(min) Min Breaking(force) Inside Length(max) Inside Width(min) MM IN MM IN KG LBS KN LBS KN LBS MM IN MM IN 7 1/4 7 0.276 1430 3150 27 6100 53.9 12100 31.5 1.24 9.8 0.38 8 5/16 8.7 0.343 2130 4700 41.6 9400 83.5 18800 33.5 1.32 12.2 0.48 10 3/8 10 0.394 2990 6600 55 12400 110 24700 35 1.38 14 0.55
Packaging & Delivery:
Packing details:
Bulk packing
Packed in wooden cases
Packed in Iron drum, then in pallets
According to your requirements
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
