• Model NO.：262-
• HS Code：8466100000
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. 262- HS Code 8466100000 Production Capacity 1000PCS/Month

Product Description

Made of hardened tool steel which is accurately ground to size. Slightly tapered with marked in the large end Standard taper 0.0005" per inch. Sizes under 1" are 0.0005" undersize on small end. Sizes 1-1/16" to 3" are 0.001" under size on small end.

Diameter	Overall Length	Model No.	Diameter	Overall Length	Model No.
3	63.5	262-1008	27	184	262-1104
4	76	262-1010	28	190.5	262-1106
5	95	262-1012	30	197	262-1112
6	95	262-1014	32	203	262-1116
7	102	262-1018	34	210	262-1120
8	102	262-1020	35	216	262-1124
9	108	262-1022	36	222	262-1128
10	114	262-1026	38	229	262-1132
11	114	262-1028	40	235	262-1136
12	127	262-1030	42	241	262-1140
13	127	262-1032	44	254	262-1148
14	133	262-1034	46	260	262-1152
15	140	262-1038	48	267	262-1156
16	140	262-1040	50	273	262-1160
17	146	262-1042	51	279	262-1200
18	152	262-1046	55	292	262-1208
19	152	262-1048	58	305	262-1216
20	159	262-1050	60	305	262-1224
21	165	262-1054	62	317.5	262-1232
22	165	262-1056	65	317.5	262-1240
23	171.5	262-1058	70	330	262-1248
25	178	262-1100	72	330	262-1256
26	184	262-1102

Overall Length	Model No.
7-1/4	262-2104
7-1/2	262-2106
7-1/2	262-2108
7-3/4	262-2110
7-3/4	262-2112
8	262-2114
8	262-2116
8-1/4	262-2118
8-1/4	262-2120
8-3/4	262-2122
8-1/2	262-2124
8-3/4	262-2128
9	262-2130
9	262-2132
9-1/4	262-2136
9-1/2	262-2140
9-3/4	262-2144
10	262-2148
10-1/4	262-2152
10-1/2	262-2156
10-3/4	262-2160
11	262-2200
11-1/2	262-2208
12	262-2216
12	262-2224
12-1/2	262-2232
12-1/2	262-2240
13	262-2248
13	262-2256
13	262-2300
