DIN580 Electric Galvanizing Stainless Steel Eye Screw
Weifang First Rigging Co., Ltd.- Material：Stainless Steel,Alloy Steel
- Color：Silver
- Product Name：Eye Screw DIN580
- Transport Package：Wooden Cases , Export Carton Then in Pallet
- Specification：M6~M30
- Trademark：First Rigging
Base Info
- Model NO.：FST-DHLS-005
- Origin：Shandong China(Mainland)
- HS Code：7326909000
- Production Capacity：1*20FT Container Per Month
Description
Basic Info.
Model NO. FST-DHLS-005 Origin Shandong China(Mainland) HS Code 7326909000 Production Capacity 1*20FT Container Per MonthProduct Description
Eye Screw DIN580:
Material: Stainless Steel
Surface treatment: Galvanized
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
Technical Specification:
| SIZE | A | B | C | D | E | F | H | W.L.L. | N.W. |
| mm | mm | mm | mm | mm | mm | mm | mm | Lbs | g/pcs |
| M6 | 6 | 17 | 28 | 16 | 6 | 13 | 25.5 | 0.07 | 60 |
| M8 | 8 | 20 | 36 | 20 | 6 | 15 | 36 | 0.14 | 62 |
| M10 | 10 | 25 | 45 | 25 | 8 | 18 | 44.5 | 0.23 | 110 |
| M12 | 12 | 30 | 54 | 30 | 10 | 22 | 53 | 0.34 | 180 |
| M14 | 14 | 35 | 63 | 35 | 12 | 28 | 61.5 | 0.52 | 290 |
| M16 | 14 | 35 | 63 | 35 | 12 | 28 | 61.5 | 0.7 | 280 |
| M20 | 16 | 40 | 72 | 40 | 12 | 30 | 71 | 1.2 | 430 |
| M22 | 18 | 45 | 81 | 45 | 14 | 35 | 80.5 | 1.5 | 860 |
| M24 | 20 | 50 | 90 | 50 | 16 | 38 | 90 | 1.8 | 860 |
| M30 | 24 | 65 | 108 | 60 | 20 | 45 | 109 | 3.6 | 1666 |
Packaging & Delivery:
Packing details: Packed in carton and then in pallet, Packed in wooden carton, or according to your requirements
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
