• Model NO.：ES
• Brand Name：L&R or as Per Clients′ Requirements
• Transport Package：Export Standard Package or as Client Requirement
• Specification：ISO9001: 2008
• Trademark：L&R or according to customer′s requirement
• Origin：Wenzhou, Zhejiang
• Production Capacity：20, 000PCS,Month

Basic Info.

Model NO. ES Brand Name L&R or as Per Clients′ Requirements Transport Package Export Standard Package or as Client Requirement Specification ISO9001: 2008 Trademark L&R or according to customer′s requirement Origin Wenzhou, Zhejiang Production Capacity 20, 000PCS/Month

Product Description

origin: Zhejiang, China
brand name: as per customers' requirements
usage: for connection of wires
Material:aluminium
packing: cartons or as requested

Description

The assembly is made of the suspension clamp itself equipped with an adjustable grip device, the body is linked to the aluminium alloy die casted bracket by a movable link

Suspension clamp and movable link are made of anti UV stabilized black thermoplastic fiber glass reinforced.

This assembly is ready to be installed on the pole using either one bolt M16 or 2stainless steel straps 20x0.7mm

Features & Benefits

Range taking 25-95 mm²

Delivered as one assembly

No tool needed for the installation thanks to the adjustable grip device

Equipped with a movable link which allows articulation between the clamp and the bracket

End stops on the bracket to ensure movement limitation of the clamp

Bracket is specially designed to install directly the pulley on it during LV ABC lines erection

All the components are not losable Perfomances

This suspension assembly is in line with the French standard NF C 33 040 and the new European standard EN 50483-3

Mechanical tests (breaking load of 12kN)

Slip tests on cables (no slippage below 300N)

Dielectric voltage test (4kV in air)

Environmental tests (climatic and corrosion)


CODE	CONDUCTORRANGE(MM2)	STANDARD
ZC94	16-95MM2	NFC33-040
ZC95	16-95MM2	NFC33-040
1.1A	16-95MM2	NFC33-040
1.1B	16-95MM2	NFC33-040
ES54-14	16-95MM2	NFC33-040
PS1500	16-95MM2	NFC33-040
SHC-1	4X16-35	NFC33-040
SHC-2	4X120+50	NFC33-040
SHC-3	4X50-70	NFC33-040
SHC-4	4X50-70	NFC33-040
SHC-5	4X70-95	NFC33-040
SHC-6	4X70-95	NFC33-040
