DIN580 Stainless Steel Eye Nut Electric Galvanizing
Weifang First Rigging Co., Ltd.- Material：Stainless Steel,Alloy Steel
- Color：Silver
- Product Name：Eye Nut DIN580
- Transport Package：Wooden Cases , Export Carton Then in Pallet
- Specification：M6~M30
- Trademark：First Rigging
Base Info
- Model NO.：FST-DHLM-005
- Origin：Shandong China(Mainland)
- HS Code：7326909000
- Production Capacity：1*20FT Container Per Month
Description
Basic Info.
Model NO. FST-DHLM-005 Origin Shandong China(Mainland) HS Code 7326909000 Production Capacity 1*20FT Container Per MonthProduct Description
Eye Nut DIN580:
Material: Stainless Steel
Surface treatment: Galvanized
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
Technical Specification:
| SIZE | A | B | M | D | E | H | W.L.L. | N.W. |
| mm | mm | mm | mm | mm | mm | mm | Lbs | g/pcs |
| M6 | 6 | 20 | 6 | 20 | 8.5 | 36 | 0.07 | 49 |
| M8 | 8 | 20 | 8 | 20 | 8.5 | 36 | 0.14 | 50 |
| M10 | 10 | 25 | 10 | 25 | 10 | 44.5 | 0.23 | 90 |
| M12 | 12 | 30 | 12 | 30 | 11 | 53 | 0.34 | 160 |
| M14 | 14 | 35 | 14 | 35 | 12 | 61.5 | 0.52 | 200 |
| M16 | 14 | 35 | 16 | 35 | 13 | 61.5 | 0.7 | 240 |
| M20 | 16 | 40 | 20 | 40 | 16 | 71 | 1.2 | 360 |
| M22 | 18 | 45 | 22 | 45 | 18 | 80.5 | 1.5 | 580 |
| M24 | 20 | 50 | 24 | 50 | 20 | 90 | 1.8 | 720 |
| M30 | 24 | 65 | 30 | 60 | 25 | 109 | 3.6 | 1320 |
Packaging & Delivery:
Packing details: Packed in carton and then in pallet, Packed in wooden carton, or according to your requirements
Delivery Detail: Usually 30 days after receiving your irrevocable L/C or advance payment.
